Machine dimensions
Compare the stated machine envelope with your access opening. Working and transport dimensions describe different arrangements; keep them separate when planning loading.
Small Road Rollers / SERIES
FYSVH700 Series
A walk-behind single-drum roller series. Machine dimensions, package size, travel and the engine option are listed separately for access and transport planning.
Series references are shown separately from individual suffix configurations.
Images are representative. Final configuration may vary by specification.
Operating weight550 kgSeries reference
Drum width700 mmSeries reference
Dimensions & weight
| Operating weight | 550 kg |
|---|---|
| Full width | 880 mm |
| Full length — armrests flat | 2150 mm |
| Full height — armrest upright | 1870 mm |
| Package dimensions (L × W × H) | 1200 × 920 × 1920 mm |
Drum & compaction
| Drum width | 700 mm |
|---|---|
| Static line load | 45 N/cm |
| Drum diameter | 530 mm |
| Vibration frequency | 70 Hz |
| Vibration amplitude | 0.6 mm |
| Exciting force | 30 kN |
Power options
| Engine oil capacity | 1.1 L |
|---|
HONDA GX270 option
| Engine model | GX270 |
|---|---|
| Engine type | Gasoline four-stroke |
| Engine power | 6.7 kW |
| Rated engine speed | 3600 rpm |
| Fuel tank capacity | 6.5 L |
Read each engine option as a separate configuration. Confirm its availability and correspondence to the code in your quotation.
Travel & capacities
| Travel speed | 0-4.5 km/h |
|---|---|
| Theoretical gradeability | 30 % |
| Hydraulic oil capacity | 15 L |
| Water tank capacity | 20 L |
Gradeability is a stated climbing reference, not a permissible working slope. Use the supplied operating guidance and site assessment for safe operation.
Codes grouped in this series
FYSVH700
These codes share a catalogue series group. Engine, suffix and component correspondence must be confirmed before choosing an individual configuration.
Reading these specifications
Drum & compaction dimensions
Drum width describes the steel drum, not the overall machine or the minimum access opening. Drum diameter is a separate measurement.
Engine & power
Engine identity and power ratings belong to the configuration stated in the table. Where alternatives are listed, read each engine and rating together; they are not one combined standard package.
Travel & control
Travel speed describes machine movement, not engine output. A remote-control distance is a stated reference and does not establish a safe operating separation for every site.
Specify your configuration
Specify the engine and starting arrangement for the quoted FY code. Confirm the unpacked loading envelope separately from the package dimensions.
